Set Specific Directions
Jango Fett’s UCS Firespray-Class Starship (75409) — wall mount
Fit the adapter at the UCS Firespray’s original stand connection and secure it with both supplied zip ties before sliding the set onto the wall cleat. Use the original video for adapter orientation and tie routing.
Reference 75409
YOUR SELECTED ITEM
Wall Mount for LEGO® Jango Fett's Firespray-Class Starship UCS (75409)
These instructions apply to this item. Follow the steps below and any item-specific notes.
Purchase this itemBefore you start
Tools needed
- Screwdriver
- Level
- Fine-tip pencil
- Tape measure
- Stud finder and drill, if required by your wall hardware
Parts & hardware
- Wall cleat
- Dedicated set adapter
- 2 included zip ties
- Wall screws and anchors appropriate for your wall (supplied only if ordered)
SOURCE YOUR OWN HARDWARE
Need mounting hardware?
If you did not order mounting hardware with your mount, use the specifications and links below to source the hardware you need.
Screws & Anchors (White/Blue)
- Specifications
- 25.0-lb 3/16-in x 1-1/4-in Push-In Anchors with Screws
SEE IT COME TOGETHER
Watch the installation
Watch on YouTubeFollow along with the installation ↗Opens in a new tab so you can keep these instructions handy.
Identify the mount parts
Identify the wall cleat and custom adapter for UCS set 75409. Watch the video before starting. This mount differs from the mount for the smaller Jango Fett’s Starship 75433.
Prepare and secure the wall cleat
Choose a location with room for the complete set and clearance from nearby objects. Use screws and, where needed, anchors suitable for your wall material and the combined weight of the mount and set. Follow the hardware manufacturer’s instructions for hole size and installation. Check for concealed services before drilling. Hold the mounting part in position, check its alignment with a level, and mark the holes. Line up the mount with the prepared holes. Start the screws, check the alignment, then tighten gradually with a screwdriver until the mount is firm against the wall. Do not overtighten or bend the printed mounting points. If the mount moves or rocks, correct the installation before adding your set.
Fit the adapter at the stand connection
Support the model and locate the connection used by its original display stand. Test-fit the adapter at that same location, matching the video’s orientation. Check that it is fully seated without forcing surrounding pieces apart.
Secure the adapter with both zip ties
With the model supported, route both supplied zip ties as shown in the original installation video to secure the adapter to the set. Tighten only enough to retain the connection without distorting parts. Recheck the fit before lifting the set and sliding its adapter onto the wall cleat.
Slide the set onto the cleat
Support the model with both hands, align its adapter with the wall cleat, and slide it down into place. Check that it is fully seated before releasing support; do not rely on sound alone to confirm engagement.
Check the finished display
Gradually release your support only after the set is fully seated and stable. Check that the wall mount, adapter, and brick connections remain secure. If anything shifts or loosens, remove the set and correct the problem before displaying it. Support the set whenever you adjust or remove it.
